| 阀体材料: |
Steel |
| 连接 2 尺寸: |
1/8-27 |
| 连接 1 尺寸: |
4 mm O.D. |
| 品牌: |
Ermeto |
| 产品序列: |
EO Very Light |
| 分部: |
High Pressure Connectors Europe Division |
| 形状: |
Elbow 90° |
| 技术: |
Fluid & Gas Handling |
| 连接 1 类型: |
Male 24° Cone |
| 行业: |
Agriculture, Automotive, Construction, Industrial Manufacturing Equipment, Marine, Material Handling, Transportation |
| 连接 2 类型: |
Male NPT |
| 连接 3 类型: |
n/a |
| 连接 3 尺寸: |
n/a |
| 可选配件: |
n/a |
| 应用: |
Chemical Transfer, Fuel Transfer, Hydraulics, Mobile Hydraulics, Oilfield, Packaging |
| 产品类型: |
Hydraulic DIN Fittings |
| 产品风格: |
Stud Fitting |
| 产品序列: |
EO Very Light |
| 配置: |
Tube to Port |
| ***大运行压力: |
100 bar |
| 形状: |
Elbow 90° |
| 连接 1 类型: |
Male, 24° Cone |
| 连接 1 尺寸: |
4 mm (Tube O.D.) |
| 连接 2 类型: |
Male, NPT |
| 连接 2 尺寸: |
1/8-27 |
| 符合规格: |
DIN, ISO 8434, SAE J476 |
| 与流体类型共同使用: |
Hydraulic Fluids, Chemical Fluids, Fuels, Gases, Steam |
| 包括附件: |
n/a |
| 阀体材料: |
Steel |
| 密封类型: |
Sealing Edge |
| 密封材料: |
Metal |
| ***高环境温度: |
300 °C, 572 °F |
| ***低环境温度: |
-40 °C, -40 °F |
| ***高流体温度: |
300 °C, 572 °F |
| ***低流体温度: |
-40 °C, -40 °F |
